Unparalleled Sound Inspired By the CLX
Amazing mid-range clarity and openness inspired by the CLX loudspeaker is only half of the story. Summit X is the first hybrid electrostatic speaker to bring controlled dispersion to low frequencies. Using a precision Vojtko Voiced™ crossover network to apply variable phasing near the crossover point, Summit X's Controlled Dispersion PoweredForce™ technology provides seamless blending with the XStat™ transducer. Four innovative modular feet adjust vertical dispersion over a 12 degree range, while the 25 and 50Hz level controls fine-tune woofer output to provide smooth, clean, and powerful bass throughout the listening environment.
Summit X Awards:
2015 The Absolute Sound 2015 Editors' Choice
2014 The Absolute Sound 2014 Golden Ear Award
2011 Golden Ear Award
2010 Best Buys - First Place Speaker of the Year: HiTech Magazine (Greece)
2009 Prroduct of the Year - Innovation in Design: SoundStage! (www.soundstage.com)
Summit X Specifications:
Frequency Response: 24–23,000 Hz ±3dB
High Frequency Transducer: XStat™ CLS™ electrostatic transducer
Panel Dimensions: 44" × 11.3" (112 × 29cm)
Low Frequency Transducer: Two 10" (25.4cm) cast basket, high excursion, aluminum cone with extended throw drive assembly, non-resonance asymmetrical chamber format
Woofer Amplifier: 2 × 200 watts/channel (4 ohms)
Sensitivity: 91 dB/2.83 volts/meter
Impedance: 4 Ohms, 0.8 at 20kHz. Compatible with 4, 6, or 8 Ohm rated amplifiers.
Recommended Amplifier Power: 20?600 watts per channel
Audio Controls: ±10dB at 25Hz, ±10dB at 50Hz
Lighting: Control knob to adjust illuminated blue hood logo, back control panel lighting & ground effects lighting
Inputs: Custom 5-way binding posts
Weight: 75 lbs. (34 kg)
Dimensions: 60.9" × 12.7" × 21.3" (154.8cm × 32.2cm × 54cm)
